SEM - Hitachi TM 3030Plus Tabletop
Location: CEMOP
Responsible: Daniela Gomes
Description:
The TM3030Plus has a premium SE detector which has been incorporated in FE-SEM & VP-SEM and well-accepted by users as a high-sensitivity detector. It operates effectively under the low-vacuum environment and allows for quick SE image observation without specimen preparation.
|
Magnification |
5x ~ 30,000x or up to 120,000x withigital zoom |
|
Accelerating Voltage |
5kV, 15kV |
|
OBSERVATION MODE |
BSE:Conductor/Standard/Charge-up Reduction |
|
SIGNAL SELECTION |
BSE/SE/Mix |
|
Sample Size: |
Up to 70mm in diameter and 50mm thickness |
|
Stage Movement |
X = 35mm; Y = 35mm |
|
ELECTRON GUN |
Pre-centered cartridge filament |
|
AUTOMATIC FUNCTIONS |
Auto start, Auto focus, Auto brightness/contrast |
